LCD Character Display Modules
The list below is our standard offering. However, AZ Displays has the ability to meet our customers custom needs and designs. Please contact us for more information.
| Part Number | Image | Stock | Drawing | Series | Outline Dimensions (mm) | Viewing Area (mm) | Supply Voltage | Format | Controller IC | Polarizer Type | Backlight | Color | Fluid Type | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ACM0802C-FL-GBW |  | RFQ |
|
| ACM0802C | 58.0X32.0X8.6mm | 38.0 x 16.0 | 5.0V/3.3V | 8 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM0802C-FL-GBX | | RFQ |
|
| ACM0802C | 58.0X32.0X8.6mm | 38.0 x 16.0 | 5.0V/3.3V | 8 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM0802C-FL-GTW | | RFQ |
|
| ACM0802C | 58.0X32.0X8.6mm | 38.0 x 16.0 | 5.0V/3.3V | 8 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM0802C-FL-YBW |  | RFQ |
|
| ACM0802C | 58.0X32.0X8.6mm | 38.0 x 16.0 | 5.0V/3.3V | 8 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM0802C-FL-YTW | | RFQ |
|
| ACM0802C | 58.0X32.0X8.6mm | 38.0 x 16.0 | 5.0V/3.3V | 8 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM0802C-RN-GBW |  | RFQ |
|
| ACM0802C | 58.0X32.0X12.8mm | 38.0 x 16.0 | 5.0V/3.3V | 8 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1601C-FL-YBW | | RFQ |
|
| ACM1601C | 80.0X36.0X9.5mm | 64.5 x 14.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1601C-NLW-BBW |  | RFQ |
|
| ACM1601C | 80.0X36.0X9.5mm | 64.5 x 14.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM1601C-NLW-BBX | | RFQ |
|
| ACM1601C | 80.0X36.0X9.5mm | 64.5 x 14.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM1601C-RN-GBW | | RFQ |
|
| ACM1601C | 80.0X36.0X13.5mm | 64.5 x 14.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1601C-RN-YBW |  | RFQ |
|
| ACM1601C | 80.0X36.0X13.5mm | 64.5 x 14.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Reflective | None | - | Yellow Mode STN |
| ACM1601H-FL-YBW | | RFQ |
|
| ACM1601H | 122.0X33.0X9.5mm | 99.0 x 13.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1601H-FL-YBX | | RFQ |
|
| ACM1601H | 122.0X33.0X9.5mm | 99.0 x 13.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1601H-ML-YTW |  | RFQ |
|
| ACM1601H | 122.0X33.0X9.5mm | 99.0 x 13.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Transmissive Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1601H-RN-GTW | | RFQ |
|
| ACM1601H | 122.0X33.0X14.5mm | 99.0 x 13.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1601H-RN-YBW | | RFQ |
|
| ACM1601H | 122.0X33.0X14.5mm | 99.0 x 13.0 | 5.0V/3.3V | 16 x 1 | Sitronix ST7066U | Reflective | None | - | Yellow Mode STN |
| ACM1602B-FL-GBW | | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM1602B-FL-YBW | | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602B-FL-YBW-AK | | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602B-FLW-FBW |  | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | White | FSTN |
| ACM1602B-FLW-FBX | | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | White | FSTN |
| ACM1602B-ML-YBW | | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transmissive Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602B-NLW-BBW | | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM1602B-NLW-FBX |  | RFQ |
|
| ACM1602B | 84.0X44.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transmissive Negative | LED | White | FSTN |
| ACM1602B-RN-GBW | | RFQ |
|
| ACM1602B | 84.0X44.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1602B-RN-GBX | | RFQ |
|
| ACM1602B | 84.0X44.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1602B-RN-GTW | | RFQ |
|
| ACM1602B | 84.0X44.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1602B-RN-YBW | | RFQ |
|
| ACM1602B | 84.0X44.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Yellow Mode STN |
| ACM1602B-RN-YBX | | RFQ |
|
| ACM1602B | 84.0X44.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Yellow Mode STN |
| ACM1602K-FL-GBW | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM1602K-FL-GBX | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM1602K-FL-GTW | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM1602K-FL-GTX | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM1602K-FL-YBW | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602K-FLW-FBW | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | White | FSTN |
| ACM1602K-FLW-GBW |  | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | White | Grey Mode STN |
| ACM1602K-ML-YBW | | RFQ |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transmissive Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602K-NLW-BBW | |
497 |
|
| ACM1602K | 80.0X36.0X9.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM1602K-RN-GBW | | RFQ |
|
| ACM1602K | 80.0X36.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1602KC-NLW-BBW-R | | RFQ |
|
| ACM1602KC | 84.0X44.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM1602KW-FL-YBE | | RFQ |
|
| ACM1602KW | 80.0X36.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602S-FL-YBW | | RFQ |
|
| ACM1602S | 122.0X44.0X9.5mm | 99.0 x 24.0 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1602S-FLW-FBW | | RFQ |
|
| ACM1602S | 122.0X44.0X9.5mm | 99.0 x 24.0 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Transflective Positive | LED | White | FSTN |
| ACM1602Y-RN-GBW | | RFQ |
|
| ACM1602Y | 71.5X36.0X13.5mm | 64.5 x 16.4 | 5.0V/3.3V | 16 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1604C-FL-YBW | |
2 |
|
| ACM1604C | 87.0X60.0X9.5mm | 61.8 x 25.2 | 5.0V/3.3V | 16 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1604C-RN-GTW | | RFQ |
|
| ACM1604C | 87.0X60.0X13.5mm | 61.8 x 25.2 | 5.0V/3.3V | 16 x 4 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM1604C-RN-YBW | | RFQ |
|
| ACM1604C | 87.0X60.0X13.5mm | 61.8 x 25.2 | 5.0V/3.3V | 16 x 4 | Sitronix ST7066U | Reflective | None | - | Yellow Mode STN |
| ACM1604D-FL-GBW | | RFQ |
|
| ACM1604D | 87.0X60.0X9.5mm | 61.8 x 25.2 | 5.0V/3.3V | 16 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM1604D-FL-YBW | | RFQ |
|
| ACM1604D | 87.0X60.0X9.5mm | 61.8 x 25.2 | 5.0V/3.3V | 16 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM1604D-FL-YBX | | RFQ |
|
| ACM1604D | 87.0X60.0X9.5mm | 61.8 x 25.2 | 5.0V/3.3V | 16 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2002D-FL-YBW | | RFQ |
|
| ACM2002D | 116.0X37.0X9.5mm | 83.0 x 18.6 | 5.0V/3.3V | 20 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2002D-ML-YTW | | RFQ |
|
| ACM2002D | 116.0X37.0X9.5mm | 83.0 x 18.6 | 5.0V/3.3V | 20 x 2 | Sitronix ST7066U | Transmissive Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2002D-RN-GBW | | RFQ |
|
| ACM2002D | 116.0X37.0X13.5mm | 83.0 x 18.6 | 5.0V/3.3V | 20 x 2 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM2002E-FL-GBX | | RFQ |
|
| ACM2002E | 116.0X37.0X9.5mm | 83.0 x 18.6 | 5.0V/3.3V | 20 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM2002E-FL-YBW-R | | RFQ |
|
| ACM2002E | 116.0X37.0X9.5mm | 83.0 x 18.6 | 5.0V/3.3V | 20 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2002R-FL-GTW | | RFQ |
|
| ACM2002R | 180.0X40.0X9.5mm | 149.0 x 23.0 | 5.0V/3.3V | 20 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM2004D-FL-GBW | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM2004D-FL-GTW | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM2004D-FL-YBE | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004D-FL-YBW | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004D-FL-YBX | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004D-FL-YTW | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004D-FL-YTX | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004D-FLW-FBW | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | White | FSTN |
| ACM2004D-NLW-BBW | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM2004D-NLW-BBW-R | |
235 |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM2004D-NLW-BBX | | RFQ |
|
| ACM2004D | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM2004D-RN-GBW | | RFQ |
|
| ACM2004D | 98.0X60.0X14.0mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM2004D-RN-GBX | | RFQ |
|
| ACM2004D | 98.0X60.0X14.0mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM2004D-RN-YBW | | RFQ |
|
| ACM2004D | 98.0X60.0X14.0mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Reflective | None | - | Yellow Mode STN |
| ACM2004F-FL-GBW | | RFQ |
|
| ACM2004F | 146.0X62.5X9.0mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM2004F-FL-YBW | | RFQ |
|
| ACM2004F | 146.0X62.5X9.0mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004F-FL-YBW-R | |
127 |
|
| ACM2004F | 146.0X62.5X9.0mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004F-FL-YBX | | RFQ |
|
| ACM2004F | 146.0X62.5X9.0mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004F-FLW-GBW | | RFQ |
|
| ACM2004F | 146.0X62.5X9.0mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | White | Grey Mode STN |
| ACM2004F-FLW-GBX | | RFQ |
|
| ACM2004F | 146.0X62.5X9.0mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | White | Grey Mode STN |
| ACM2004F-RN-GBW | | RFQ |
|
| ACM2004F | 146.0X62.5X13.5mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM2004F-RN-GTX | | RFQ |
|
| ACM2004F | 146.0X62.5X13.5mm | 123.0 x 42.5 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Reflective | None | - | Grey Mode STN |
| ACM2004G-FL-YBW-R | | RFQ |
|
| ACM2004G | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM2004G-NLW-BTW | | RFQ |
|
| ACM2004G | 98.0X60.0X9.5mm | 76.0 x 25.2 | 5.0V/3.3V | 20 x 4 | Sitronix ST7066U | Transmissive Negative | LED | White | Blue Mode STN |
| ACM4002E-FL-YBW | | RFQ |
|
| ACM4002E | 182.0X33.5X9.5mm | 154.5 x 16.5 | 5.0V/3.3V | 40 x 2 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM4004E-FL-GBW | | RFQ |
|
| ACM4004E | 190.0X54.0X9.5mm | 147.0 x 29.5 | 5.0V/3.3V | 40 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Grey Mode STN |
| ACM4004E-FL-YBW | | RFQ |
|
| ACM4004E | 190.0X54.0X9.5mm | 147.0 x 29.5 | 5.0V/3.3V | 40 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
| ACM4004H-FL-YBW-R | | RFQ |
|
| ACM4004H | 190.0X54.0X9.5mm | 147.0 x 29.5 | 5.0V/3.3V | 40 x 4 | Sitronix ST7066U | Transflective Positive | LED | Yellow/Green | Yellow Mode STN |
