ATM1010L1B Product Page
Resources
Datasheet
Request a Quote
Total Qty Available: 0
| Product Specifics | |
|---|---|
| Overall Module Size | 10.1 |
| Resolution | 1280 x 800 |
| Aspect Type | Wide |
| Touch | None |
| Brightness (Nits) | 600 |
| Contrast | 800 |
| Backlight | - |
| Viewing Angle | +80/-80 +80/-80 |
| Weight | - |
| Operation Temperature (℃) | -20~+70 |
| Storage Temperature (℃) | - |
| Interface | LVDS |
| Active Area | 216.96X135.6 mm |
| Outline Dimension | 229.46X149.1 mm |
| Viewing Direction | IPS |
| Bonding Type | - |
| Pixel Configuration | - |
