ATM2412BS Digital TFT LCD Panels
Datasheet
3D CAD File (IGS)
Request a Quote
Check Distributor Stock
| Product Specifics | |
|---|---|
| Overall Module Size | 5 |
| Resolution | 240 X 128 |
| Brightness (Nits) | 250 |
| Contrast | 400 |
| Backlight | LED |
| Viewing Angle |
+80/-80 +80/-80 |
| Weight | - |
| Operation Temperature (℃) | -20~+70 |
| Storage Temperature (℃) | -30~+80 |
| Interface | SPI |
| Active Area | 113.5X64.0 mm |
| Outline Dimension | 144.0X104.0X10.0 mm |
| Viewing Direction | - |
| Bonding Type | COB |
| Pixel Configuration | Stripe |
