ATM0680L3 Digital TFT LCD Panels
Datasheet
Request a Quote
Check Distributor Stock
| Product Specifics | |
|---|---|
| Overall Module Size | 6.8 |
| Resolution | 480 X 1280 |
| Brightness (Nits) | 450 |
| Contrast | 800 |
| Backlight | LED |
| Viewing Angle |
+80/-80 +80/-80 |
| Weight | 81 g |
| Operation Temperature (℃) | -20~+70 |
| Storage Temperature (℃) | -30~+80 |
| Interface | MIPI |
| Active Area | 60.22X160.59 mm |
| Outline Dimension | 66.6X181X4.5 mm |
| Viewing Direction | IPS |
| Bonding Type | COG |
| Pixel Configuration | Stripe |
