ATM0500U27-CT Product Page
Resources
Datasheet
Request a Quote
Total Qty Available: 0
| Product Specifics | |
|---|---|
| Overall Module Size | 5 |
| Resolution | 800 X 480 |
| Brightness (Nits) | 350 |
| Contrast | 1200 |
| Backlight | LED |
| Viewing Angle | +70/-70 +70/-50 |
| Weight | - |
| Operation Temperature (℃) | -20~+60 |
| Storage Temperature (℃) | -30~+70 |
| Interface | UART |
| Active Area | 108.0X64.8mm |
| Outline Dimension | 143.5X80.9X8.05mm |
| Viewing Direction | |
| Bonding Type | - |
| Pixel Configuration | Stripe |
